Series :26K
Dimension :17 x 50 x 50 mm
Interface: PNP normally open (NO)
PNP normally closed (NC)
PNP normally closed (NC)
Principle of operation :Photoelectric sensor
Principle of optical operation: Diffuse sensor, triangulation
Special optical feature: Background suppression
Beam characteristic : Collimated
Light type :Laser red light
Light spot size: 3 x 1 mm at 300 mm
Range :50…300 mm
Connection :Connector, M12x1-Male, 4-pin
Housing material :ABS
Material sensing surface: PMMA
Operating voltage Ub: 10…30 VDC
Datasheet: view
