| Operating voltage[V] | 24 DC |
| Insulation rating[V] | 500 |
| Current consumption[mA] | < 500 |
| Max. current consumption from AS-i[mA] | 10 |
| Max. power consumption[VA] | 10 |
| Number of AS-i masters | 2 |
| Electrical separation | yes |
Interfaces
| Communication interface | RS232; PROFIBUS |
| PROFIBUS | |
|---|---|
| Transmission standard | EN 50170 |
| Transmission rate | 12 MBaud |
| Protocol | Profibus DP |
| RS232 | ||
|---|---|---|
| Transmission rate | 9600…115200 Baud | |
| Connector type | RJ11 | |
| Note on interfaces |
|
|
Operating conditions
| Ambient temperature[°C] | 0…60 |
| Storage temperature[°C] | -20…70 |
| Max. relative air humidity[%] | 95 |
| Protection | IP 20 |
AS-i classification
| AS-i version | 2.1 |
| AS-i master profile | M3 |
Mechanical data
| Weight[g] | 558 |
| Housing | housing for DIN rail mounting |
| Dimensions[mm] | 131 x 86 x 107 |
| Materials | aluminium; steel sheet galvanised |
Displays / operating elements
| Display |
|
Remarks
| Remarks |
|
||
| Notes | Replacement units for Krones systems should be obtained directly from the company Krones.; This unit is not directly compatible. | ||
| Pack quantity | 1 pcs. |
