Key Specifications



• Brand: IFM electronic (Germany)
• Model Number: IFM204
• Full Order Code: IFKC007-ASKG/M/US-104-DRS
• Sensing Distance (s): 7 mm (non-flush mountable). This means the sensing face must protrude from the surrounding metal mounting surface.

---



Electrical Data



• Operating Voltage (Ub​): 10 to 36 V DC
• Maximum Load Current (Ie​): 100 mA
• Electrical Protection: Short Circuit Protection (SCP)
• Output Type: PNP with complementary (dual) outputs. This is a key feature, as the sensor provides both a Normally Open and a Normally Closed signal at the same time.
• Wiring (4-pin M12 Connector):
  • Pin 1: +L (Positive Supply)
  • Pin 2: Output 2 (Normally Closed – NC)
  • Pin 3: -L (Negative / Ground)
  • Pin 4: Output 1 (Normally Open – NO)

---



Environmental & Protection Ratings



• IP Rating: IP67 / IP69K. This is a very high rating, indicating the sensor is fully sealed against dust and can withstand high-pressure, high-temperature water jets (washdowns).
• Protection Class: Class II (indicated by the square-within-a-square symbol), meaning it is double insulated.

---



Manufacturing & Certifications



• Designed by: IFM (Germany)
• Made in: Romania
• Certifications: CE, EAC, cULus Listed.
