Key Specifications



• Brand: IFM electronic (Germany)
• Model Number: IFT210
• Full Order Code: IFGC007-ASKG/MV4A/US-104-DRS
• Sensing Distance (s): 7 mm (non-flush mountable). This means the sensing face must protrude from the mounting surface.

---



Electrical Data



• Operating Voltage (Ub​): 10 to 36 V DC
• Maximum Load Current (Ie​): 100 mA
• Electrical Protection: Short Circuit Protection (SCP)
• Output Type: NPN with complementary (dual) outputs.
  • Important Note: This is a “sinking” output sensor, meaning it switches the load to the negative/ground (0V). This is different from PNP (“sourcing”) sensors. It provides both a Normally Open (NO) and a Normally Closed (NC) signal simultaneously.
• Wiring (4-pin M12 Connector):
  • Pin 1: +L (Positive Supply)
  • Pin 2: Output 2 (Normally Closed – NC)
  • Pin 3: -L (Negative / Ground)
  • Pin 4: Output 1 (Normally Open – NO)

---



Materials & Environmental Ratings



• Housing Material: High-grade Stainless Steel (V4A / 316L), offering excellent resistance to corrosion (inferred from ‘V4A’ in the model code).
• IP Rating: IP67 (Confirmed from official datasheet), providing full protection against dust and temporary water immersion.

---



Manufacturing & Certifications



• Designed by: IFM (Germany)
• Made in: Romania
• Certifications: CE, EAC.
• Features: Includes LED indicators for power and output status.
