Product characteristics
| Electrical design |
PNP |
| Output function |
normally open |
| Sensing range [mm] |
2 |
| Housing |
rectangular |
| Dimensions [mm] |
40 x 12 x 26 |
Electrical data
| Operating voltage [V] |
10…36 DC |
| Current consumption [mA] |
15; (24 V) |
| Protection class |
III |
| Reverse polarity protection |
yes |
Outputs
| Electrical design |
PNP |
| Output function |
normally open |
| Max. voltage drop switching output DC [V] |
2.5 |
| Permanent current rating of switching output DC [mA] |
250 |
| Switching frequency DC [Hz] |
1400 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
Detection zone
| Sensing range [mm] |
2 |
| Real sensing range Sr [mm] |
2 ± 10 % |
| Operating distance [mm] |
0…1.6 |
Accuracy / deviations
| Correction factor |
steel: 1 / stainless steel: 0.7 / brass: 0.4 / aluminium: 0.3 / copper: 0.2 |
| Hysteresis [% of Sr] |
1…15 |
| Switch point drift [% of Sr] |
-10…10 |
Operating conditions
| Ambient temperature [°C] |
-20…80 |
| Protection |
IP 67 |
Mechanical data
| Weight [g] |
19.8 |
| Housing |
rectangular |
| Mounting |
flush mountable |
| Dimensions [mm] |
40 x 12 x 26 |
| Materials |
PBT |
Displays / operating elements
| Display |
| switching status |
1 x LED, yellow |
|
Electrical connection – plug
| Connection |
Connector: 1 x M8; coding: A |
