| Type of light | infrared light |
| Housing | rectangular |
Application
| Function principle | Retro-reflective sensor |
Electrical data
| Operating voltage[V] | 10…55 DC |
| Current consumption[mA] | 40; ((24 V)) |
| Protection class | II |
| Reverse polarity protection | yes |
| Type of light | infrared light |
| Wave length[nm] | 880 |
Outputs
| Electrical design | PNP |
| Output function | light-on/dark-on mode; (parameterisable) |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 250 |
| Switching frequency DC[Hz] | 150 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Range[m] | 0.15…5; (Prismatic reflector Ø 80 E20005) |
| Range adjustable | yes |
| Max. light spot diameter[mm] | 262 |
| Light spot dimensions refer to | at maximum range |
Operating conditions
| Ambient temperature[°C] | -25…60 |
| Protection | IP 67 |
Tests / approvals
| EMC |
|
Mechanical data
| Weight[g] | 0.201 | |
| Housing | rectangular | |
| Dimensions[mm] | 75 x 19 x 30 | |
| Materials | PBT | |
| Lens material |
|
Displays / operating elements
| Display |
|
Accessories
| Items supplied |
|
