| Series | 78 |
| Operating principle | Throughbeam principle |
| Device type | Receiver |
| Protective circuit |
| Supply voltage UB | 12 … 30 V, DC |
| Residual ripple | |
| Open-circuit current |
| Number of digital switching outputs | 3 Piece(s) |
| Switching element | Transistor, PNP, NC contact/NO contact |
| Switching principle | Light/dark switchable |
| Switching element | Transistor, NPN |
| Switching principle | Light/dark switchable |
| Switching frequency | 100 Hz |
| Response time |
| Type of connection | Terminal |
| No. of pins | 8 -pin |
| Dimension (W x H x L) | 38 mm x 127 mm x 99 mm |
| Housing material | Metal |
| Metal housing | Diecast aluminum |
| Net weight | 600 g |
| Type of fastening |
| Ambient temperature, operation | -20 … 60 °C |
