Operating voltage UB 10 … 30 V DC
Switching frequency f 0 … 440 Hz
Hysteresis H 3 … 15 %
Reverse polarity protection reverse polarity protected
Short-circuit protection pulsing
Voltage drop Ud ≤ 2.5 V
Operating current IL 0 … 200 mA
Off-state current Ir 0 … 0.5 mA typ. 0.01 mA
No-load supply current I0 ≤ 25 mA
Time delay before availability tv 15 ms
Constant magnetic field B 200 mT
Alternating magnetic field B 200 mT
Operating voltage indicator LED, green
Switching state indicator LED, yellow
Functional safety related parameters
MTTFd 1123 a
Mission Time (TM) 20 a
Diagnostic Coverage (DC) 0 %

PEEPERL+FUCHS NCN3-F3IK-N4-K Inductive sensor

PEPPERL+FUCHS CBB4-12GH60-E2-V1
