| General specifications | ||
|---|---|---|
| Detection range | 20 … 700 mm | |
| Detection range min. | 20 … 200 mm | |
| Detection range max. | 20 … 700 mm | |
| Background suppression | max. + 10 % of the upper limit of the detection range | |
| Light source | LED | |
| Light type | modulated visible red light , 660 nm | |
| Black-white difference (6 %/90 %) | < 20 % | |
| Diameter of the light spot | approx. 15 mm at a distance of 700 mm | |
| Opening angle | Emitter 1.2°, Receiver 2° |
|
| Ambient light limit | 50000 Lux | |
| Electrical specifications | ||
|---|---|---|
| Operating voltage | 10 … 30 V DC | |
| Ripple | 10 % | |
| No-load supply current | ≤ 40 mA | |
| Output | ||
|---|---|---|
| Switching type | light/dark on switchable | |
| Signal output | 2 PNP, complementary, short-circuit protected, reverse polarity protected , open collectors | |
| Switching voltage | max. 30 V DC | |
| Switching current | max. 200 mA | |
| Switching frequency | 250 Hz | |
| Response time | 2 ms | |
