Features
Dimensions (W x H x D) 30.4 mm x 53 mm x 80 mm
Sensing distance ≤ 10 mm 1)
Housing design Rectangular
Light source LED, RGB 2)
Wave length 470 nm, 525 nm, 640 nm
Light emission Long and short side of housing, exchangeable
Light spot size 1.2 mm x 4.2 mm
Light spot direction Vertical 3)
Adjustment Teach-in button
Teach-in mode Static 2-point teach-in with manual fine adjustment
1) From leading edge of lens.
2) Average service life: 100,000 h at TU = +25 °C.
3) In relation to long side of housing.
Mechanics/electronics
Supply voltage 10 V DC … 30 V DC 1)
Ripple ≤ 5 Vpp
2)
Current consumption < 130 mA 3)
Switching frequency 10 kHz 4)
Response time 50 µs 5)
