General Information



• Brand: SICK
• Product Family: Sensick P / W27-2 Laser
• Product Type: Laser Photoelectric Sensor with Background Suppression
• Model: WT27L-2F430
• Part No.: 1 016 019

---



Performance Data



• Sensing Range: 100 mm to 1,000 mm
• Light Source: Laser (Visible Red Light, Laser Class 2).

---



Electrical Data



• Supply Voltage: 10V to 30V DC
• Max. Output Current: 0.1 A (100 mA)
• Output Type: PNP with complementary (dual) outputs.
• Connection: M12, 4-pin male connector.
• Pinout:
  • 1 (Brown): L+ (10-30V DC Supply)
  • 2 (White): Q̄ (Normally Closed Output)
  • 3 (Blue): M (Ground)
  • 4 (Black): Q (Normally Open Output)

---



Mechanical & Environmental Data



• IP Rating: IP65
• Adjustment: Potentiometer (5-turn) for setting the sensing distance.
• Housing Material: Plastic (ABS)
• Protection Class: II (Double Insulated)

---



Manufacturing



• Made in: Hungary

data sheet

SICK WT27L-2F430A
