Key Specifications



• Brand: Siemens
• Product Line: SIMATIC PXI300
• Model Number: 3RG4013-3AA00
• Sensor Type: Inductive Proximity Switch
• Nominal Sensing Distance (Sn​): 5 mm
• Mounting: Non-flush mountable (the sensing face must protrude from any surrounding metal).

---



Electrical Data



• Operating Voltage: 10V to 65V DC. This very wide range provides excellent flexibility for different power supplies.
• Output Type: PNP, 3-wire, Normally Closed (NC).
  • Important Note: A Normally Closed output is ON by default and turns OFF when a metal object is detected. This is the opposite of a Normally Open (NO) sensor.
• Maximum Load Current: 0.3 A (300 mA).

---



Mechanical & Connection Data



• Body Size: M12 (inferred from the “13” in the model number).
• Connection Type: 3-pin M12 connector.
• Wiring:
  • Pin 1: L+ (Positive Supply)
  • Pin 2: Signal Output
  • Pin 3: L- (Negative / Ground)

---



Manufacturing & Certifications



• Manufacturer: Siemens
• Made in: Czech Republic
• Enclosure Rating: Type 4X / 12 (for indoor use only).
• Certifications: CE, UL Listed, CSA Certified.
