combi prox® Inductive Sensor



Model: Ni35-CP40-VP4X2

---



1. General Description



The Ni35-CP40-VP4X2 is a high-performance inductive proximity sensor from Turck’s combi prox® series. It is designed for the non-contact detection of metallic objects at a significantly long range. A key feature of this sensor is its extremely flexible wide operating voltage range (10-65 VDC), making it suitable for a vast array of industrial applications.

Housed in a robust rectangular CP40 housing, it provides complementary outputs (one normally open and one normally closed), offering greater flexibility for control logic in applications like logistics, automotive manufacturing, and machine building.



Key Features 🎯



• Extended Sensing Range: A nominal sensing distance of 35 mm.
• Universal Voltage Range: Operates on any DC voltage from 10 to 65 V, simplifying integration.
• Complementary Outputs: Provides both Normally Open (NO) and Normally Closed (NC) PNP outputs simultaneously.
• Durable Housing: Rectangular plastic housing with high shock and vibration resistance.
• High Visibility LEDs: Features corner LEDs for a clear 360° visual indication of power and switching status.
• High Protection: Rated at IP68, making it fully dust-tight and suitable for prolonged submersion in water.

---



2. Technical Specifications





Sensing & Electrical Data





Mechanical & Environmental Data



---



3. Wiring Diagram (M12 Connector)



The wiring diagram on the label indicates a standard 4-pin configuration:

• Pin 1: + (Brown Wire) – Connect to Positive (+) 10-65 VDC
• Pin 2: Output 2 (White Wire) – NC (Normally Closed) PNP Output
• Pin 4: Output 1 (Black Wire) – NO (Normally Open) PNP Output
• Pin 3: - (Blue Wire) – Connect to Ground (-)
