Display/Operation
Function indicator yes
Power indicator no Electrical connection
Cable diameter D 3.10 mm
Cable length 0.05 m
Connection M8x1-Connector, 3-pole
Connection type Cable with connector, 0.05 m,
PUR
Polarity reversal protected yes
Short-circuit protection yes
Electrical data
Hysteresis H max. (% of Sr) 15.0 %
Load capacitance max. at Ue 1 µF
MTTF (40 °C) 860 a
No-load current lo max., undamped 12 mA
Operating voltage Ub 10…30 VDC
Output resistance Ra 2.2 kOhm + D + LED
Pollution degree 3
Protected against miswiring yes
Rated insulation voltage Ui 75 V DC
Rated operating current Ie DC 130 mA
Rated operating voltage Ue DC 24 V
Rated short circuit current 100 A
Ready delay tv max. 10 ms
Repeat accuracy max. (% of Sr) 5.0 %
Residual current Ir max. 80 µA
Switching frequency 800 Hz
Utilization category DC -13
Voltage drop static max. 3.5 V
Environmental conditions
Ambient temperature -25…70 °CProtection type IEC 60529 IP67Functional safety
Diagnostic coverage 0 %Functional safety noMission Time 20 aGeneral data
Approval/Conformity CE
cULus
EACBasic standard IEC 60947-5-2Material
Housing material Stainless steel
Material jacket PURMaterial sensing surface PBTMechanical data
Dimension Ø 8 x 35.5 mmInstallation for flush mountingSize D8.0Output/Interface
Switching output PNP Normally open (NO)
