Mechanical Data
Measurements BxHxT or DxT M18x1 x 65mm
Housing material CuZn, PTFE coated
Material of sensing face LCP + PTFE
Degree of protection IP67IP
Connection Connector S4 (M12)
Schock: Halfsinus, 30 gn, 11ms
Vibration: 55 Hz, 1mm Amplitude, 3 x 30 Minutes
Electrical Data
Current type DC
Wiring 3-Wire
switching function normally-open
Output signal PNP
Rated opertional voltage 24 DCV
Rated opertional current 200mA
Supply voltage 10…30 DCV
Ripple 10%
Rated supply frequency DCHz
max. switching frequency 2500Hz
No-load supply current 15/ 10mA
Off-state current 80µA
Voltage drop 2.5/-V
Short circuit protection yes
Protected against polarity reversal yes
