Usage
Compressed air, water technology, construction machinery, fire
extinguishing systems (water), oil pressure monitoring
Application
Pressure switches of the MDR-F series are universally applicable and can be used as follows:
Monitoring and control of pressure of liquid and gases in pipelines,
boilers, pressure tanks and devices.
Process control, cooling and compressed air technology, hydraulic
applications.
Pressure monitoring of cooling and lubrication systems in different types of machinery.
Automatic switching of compressors and pump motors, e.g. for water supply, additional pumps, fire extinguishing systems and compressed air systems. Technical data
Operating measuring current I, AC 1-10 A, AC 15-4 A, DC 13-0.1 A
Motor power: 230 V, 0.55 kW
Vibration resistance (10 to 1000 Hz): 4 g
Type of protection: IP 54
Ambient temperature range: – 20C°..+70C°
