Electrical data
| Operating voltage[V] | 26.5…31.6 DC |
| Max. current consumption from AS-i[mA] | 150 |
| Integrated watchdog | yes |
Inputs / outputs
| Number of inputs and outputs | Number of digital inputs: 2; Number of pneumatic outputs: 2 |
Inputs
| Number of digital inputs | 2 |
| Input circuit of digital inputs | PNP |
| Sensor supply of the inputs | AS-i |
| Power supply[V] | 20…30 |
| Max. total current rating of inputs[mA] | 100 |
| Input current High[mA] | > 3 |
| Input current Low[mA] | < 1.5 |
| Switching level high[V] | > 10 |
| Digital inputs protected against short circuits | yes |
Outputs
| Number of pneumatic outputs | 2 |
| Actuator supply outputs | AS-i |
Operating conditions
| Ambient temperature[°C] | 0…55 | ||
| Note on ambient temperature |
|
||
| Storage temperature[°C] | -20…80 | ||
| Max. relative air humidity[%] | 90; (non condensing) | ||
| Max. height above sea level[m] | 2000 | ||
| Protection | IP 65 | ||
| Pollution degree | 2 |
