Product characteristics
| Type of light |
red light |
| Housing |
rectangular |
Application
| Special feature |
polarisation filter |
| Function principle |
Retro-reflective sensor |
Electrical data
| Operating voltage [V] |
10…30 DC |
| Current consumption [mA] |
< 30 |
| Protection class |
II |
| Reverse polarity protection |
yes |
| Type of light |
red light |
| Wave length [Nm] |
660 |
Outputs
| Electrical design |
PNP |
| Output function |
complementary |
| Max. voltage drop switching output DC [V] |
2.9 |
| Permanent current rating of switching output DC [mA] |
100 |
| Switching frequency DC [Hz] |
1500 |
| Short-circuit protection |
yes |
| Type of short-circuit protection |
pulsed |
| Overload protection |
yes |
Detection zone
| Range [m] |
< 5 |
| Range adjustable |
yes |
| Max. light spot diameter [mm] |
130 |
| Light spot dimensions refer to |
at maximum range |
| Polarisation filter available |
yes |
Operating conditions
| Ambient temperature [°C] |
-40…60 |
| Protection |
IP 67 |
Mechanical data
| Housing |
rectangular |
| Dimensions [mm] |
49 x 15 x 42 |
| Materials |
diecast zinc |
| Lens material |
|
Displays / operating elements
| Display |
| switching status |
1 x LED, yellow |
| function |
1 x LED, yellow flashing |
|
Electrical connection
| Connection |
Connector: 1 x M12 |
