Key Specifications



• Brand: IFM electronic
• Model Number: IFS204
• Full Order Code: IFB3004BBPKG/US-104
• Sensing Distance (s): 4 mm (flush mountable).
  • Mounting Note: “Flush” means the sensor body can be mounted level (embedded) within a surrounding metal surface. This is different from non-flush sensors which must protrude.

---



Electrical Data



• Operating Voltage (Ub​): 10 to 30 V DC
• Maximum Load Current (Ie​): 100 mA
• Electrical Protection: Short Circuit Protection (SCP)
• Output Type: PNP, 3-wire, Normally Open (NO).
• Wiring (M12 Connector):
  • Pin 1: +L (Positive Supply)
  • Pin 3: -L (Negative / Ground)
  • Pin 4: Signal Output

---



Environmental & Protection Ratings



• IP Rating: IP67. Provides full protection against dust ingress and temporary immersion in water.
• Protection Class: Class II (Double Insulated).
• Enclosure Type: 1.

---



Manufacturing & Certifications



• Designed by: IFM (Germany)
• Made in: Germany
• Certifications: CE, EAC, UKCA, and cULus Listed.
