| Type of light | infrared light |
| Housing | rectangular |
Application
| Function principle | Diffuse reflection sensor |
Electrical data
| Operating voltage[V] | 10…55 DC |
| Current consumption[mA] | 30; ((24 V)) |
| Protection class | II |
| Reverse polarity protection | yes |
| Type of light | infrared light |
| Wave length[nm] | 880 |
Outputs
| Electrical design | PNP |
| Output function | light-on/dark-on mode; (programmable) |
| Max. voltage drop switching output DC[V] | 2.5 |
| Permanent current rating of switching output DC[mA] | 250 |
| Switching frequency DC[Hz] | 100 |
| Short-circuit protection | yes |
| Type of short-circuit protection | pulsed |
| Overload protection | yes |
Detection zone
| Range[mm] | < 1000; (white paper 200 x 200 mm) |
| Range adjustable | yes |
Operating conditions
| Ambient temperature[°C] | -25…80 |
| Protection | IP 65 |
Tests / approvals
| EMC |
|
||||
| MTTF[years] | 639 |
Mechanical data
| Weight[g] | 275 | |
| Housing | rectangular | |
| Dimensions[mm] | 80 x 28 x 95 | |
| Materials | PPO modified | |
| Lens material |
|
|
| Lens alignment | side lens |
Displays / operating elements
| Display |
|
Accessories
| Items supplied |
|
Remarks
| Pack quantity | 1 pcs. |
Electrical connection
| Connection | terminals: …1.5 mm²; Cable gland: M20 X 1.5 |
