Type of light infrared light
Housing threaded type

Application

Function principle Retro-reflective sensor

Electrical data

Operating voltage[V] 10…55 DC
Current consumption[mA] 30; ((24 V))
Protection class II
Reverse polarity protection yes
Type of light infrared light
Wave length[nm] 950

Outputs

Electrical design PNP
Output function light-on/dark-on mode; (programmable)
Max. voltage drop switching output DC[V] 2.5
Permanent current rating of switching output DC[mA] 250
Switching frequency DC[Hz] 65
Short-circuit protection yes
Type of short-circuit protection pulsed
Overload protection yes

Detection zone

Range referred to prismatic reflector[m] 0.1…4; (Prismatic reflector Ø 80 E20005)
Range adjustable yes
Max. light spot diameter[mm] 280
Light spot dimensions refer to
