| Series | 72 |
| Operating principle | Reflection principle |
| Operating range | 0.1 … 4 m |
| Operating range limit | 0.1 … 6 m |
| Light source | LED, Infrared |
| Protective circuit | Polarity reversal protection |
| Supply voltage UB | 12 … 30 V, DC |
| Number of digital switching outputs | 1 Piece(s) |
| Switching element | Transistor, PNP |
| Switching principle | Light/dark switchable |
| Switching frequency | 100 Hz |
| Response time | 5 ms |
| Type of connection | Standard plug |
| No. of pins | 4 -pin |
| Dimension (W x H x L) | 15 mm x 90 mm x 35 mm |
| Housing material | Metal |
| Metal housing | |
| Lens cover material | Glass |
| Net weight | g |
| Type of fastening | Through-hole mounting Via optional mounting device |
| Ambient temperature, operation | -20 … 60 °C |
