PNOZ sigma Safety Relay, 24 Vdc

The Pilz PNOZ sigma series Safety Relay meets the requirements of EN 60947-5-1, EN 60204-1 and VDE 0113-1 and may be used in applications with E-Stop, Safety gates and light beam devices. Featuring 3 safety contacts which are Normally Open (NO) and 1 Normally closed (NC) and 1 semiconductor. Featuring connection options for the monitoring of for E-Stop pushbuttons, safety gate limit switch, reset buttons, light barriers and PSEN.
Designed to last, this relay meets the following safety requirements: The circuit is redundant with built in self-monitoring. The component remains effective in the case of component failure. The correct opening and closing of the safety function relay is tested automatically in each on-off cycle and the unit has an electronic fuse.

PNOZ Safety Relay Features

• DIN rail mounting
• 24 Vdc supply voltage
• 3 Normally Open contacts, 1 Normally Closed, 1 Semiconductor
• Operating modes, single channel, automatic reset, dual channel
• Screw terminals
• Operating temperature ranges between -10°C and 55°C
