Features
Functional principle Through-beam photoelectric sensor
Dimensions (W x H x D) 36 mm x 85 mm x 72 mm
Housing design (light emission) Rectangular
Sensing range max. 0 m … 60 m
Sensing range 0 m … 50 m
Type of light Infrared light
Light source LED
Mechanics/electronics
Supply voltage 10 V DC … 30 V DC
Ripple < 5 Vpp
Current consumption 40 mA 1)
Switching mode Light/dark switching
Response time ≤ 2.5 ms 2)
Connection type Terminal, PG11
Housing material Plastic, Glassfibre reinforced plastic
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –40 °C … +55 °C
Ambient temperature, storage –40 °C … +70 °C
