eatures
-
Functional principle Photoelectric retro-reflective sensor Functional principle detail Dual lens Dimensions (W x H x D) 12 mm x 40 mm x 22 mm Housing design (light emission) Rectangular Sensing range max. 0.1 m … 12 m 1) Sensing range 0.1 m … 8 m 1) Type of light Visible red light Light source Laser 2) Light spot size (distance) Ø 1 mm (500 mm) Laser class 2 (IEC 60825-1 / CDRH 1040.10) Adjustment Single teach-in button -
1) Reflector PL80A.
-
2) Average service life: 50,000 h at TU = +25 °C.
-
-
Mechanics/electronics
-
Supply voltage 10 V DC … 30 V DC 1) Ripple < 5 Vpp 2) Current consumption 35 mA Switching output PNP Output function Complementary Switching mode Light/dark switching Signal voltage PNP HIGH/LOW Approx. VS – 2.0 V / 0 V Output current Imax. ≤ 100 mA Response time < 0.6 ms 3) Switching frequency 1,000 Hz 4) Connection type Male connector M12, 4-pin Circuit protection A 5)
B 6)
C 7)
Protection class III 8) Weight 20 g Polarisation filter ✔ Housing material Plastic, ABS Enclosure rating IP67 Ambient operating temperature –10 °C … +50 °C Ambient temperature, storage –25 °C … +70 °C
