Features
-
Dimensions (W x H x D) 12 mm x 38.5 mm x 59 mm Housing design (light emission) Rectangular Sensing range max. 0 mm … 2,000 mm 1) Sensing range 0 mm … 400 mm 1) Type of light Visible red light Light source LED Wave length 660 nm -
1) Object with 90 % reflectance (referred to standard white, DIN 5033).
-
-
Mechanics/electronics
-
Supply voltage 10 V DC … 30 V DC Ripple ± 10 % Current consumption 30 mA 1) Switching output PNP Switching mode Light/dark switching Response time ≤ 0.35 ms 2) Connection type Male connector M8, 4-pin Housing material Plastic, ABS Optics material Plastic, PMMA Enclosure rating IP67 Ambient operating temperature –25 °C … +55 °C Ambient temperature, storage –40 °C … +70 °C
