Features
Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression
Dimensions (W x H x D) 17 mm x 75 mm x 32.5 mm
Housing design (light emission) Rectangular
Sensing range max. 50 mm … 600 mm 1)
Sensing range 50 mm … 600 mm 1)
Type of light Visible red light
Light source LED
Adjustment Potentiometer
1) Object with 90% remission (based on standard white, DIN 5033).
Mechanics/electronics
Supply voltage 10 V DC … 30 V DC
Ripple < 5 Vpp
Current consumption 25 mA 1)
Switching output PNP
Switching mode Light/dark switching
Response time < 700 µs 2)
Connection type Male connector M12, 4-pin
Housing material Plastic, ABS
Plastic, ABS
Optics material Plastic, PMMA
Enclosure rating IP67
Ambient operating temperature –40 °C … +60 °C
