Rated operating distance Sn 35,0 mm
Mounting mode non-flush
Hysteresis H 3…15 %
Max. relative temperature drift ≤ 15 % v.E
Min. repeat accuracy ≤ 2 % v.E
Operation temperature -30…85 °C
Rated operational voltage (DC) Ue 10…30 VDC
Max. ripple ≤ 10 % Uss
Rated operational current (DC) Ie 200 mA
No-load current I0 ≤ 15,0 mA
Max. OFF-state current ≤ 0,1 mA
Max. switching frequency ≤ 0,25 kHz
Rated insulation voltage 0,5 kV
Output function normally open, PNP
Short-circuit protection yes, cyclic
Max. voltage drop at Ie ≤ 1,8 V
Wire brakage and reverse polarity protection yes, complete
Degree of protection / protection class IP 67; 2
Housing style rectangular; CK40
Dimensions 60,0 x 40,0 x 40,0 mm
Housing material metal; PBT-GF30-V0
Active face plastic; PBT-GF30-V0
Wiring connector; M12x1 eurocon
Vibration resistance 55 Hz (1 mm)
Shock resistance 30 x g (11 ms)
Supply voltage indication LED; grün
Switching status indication LED; yellow
Included with sensor BS4-CK40
