Optical Data |
|
|---|---|
| Range | 400 mm |
| Setting Range | 65 … 400 mm |
| Switching Hysteresis | < 1 % |
| Light Source | Laser (red) |
| Wavelength | 655 nm |
| Service Life (T = +25 °C) | 100,000 h |
| Laser Class (EN 60825-1) | 2 |
| Max. Ambient Light | 10,000 Lux |
| Light Spot Diameter | see Table 1 |
Electrical Data |
|
|---|---|
| Supply Voltage | 10 … 30 V DC |
| Current Consumption (Ub = 24 V) | < 20 mA |
| Switching Frequency | 600 Hz |
| Response Time | 833 µs |
| Temperature Drift | < 2 % |
| Temperature Range | -25 … 60 °C |
| Switching Output Voltage Drop | < 2.5 V |
| PNP Switching Output/Switching Current | 200 mA |
| Contamination Output Voltage Drop | < 2.5 V |
| PNP Contamination Output/Switching Current | 50 mA |
| Short Circuit Protection | yes |
| Reverse Polarity Protection | yes |
| Overload Protection | yes |
| Protection Class | III |
Mechanical Data |
|
|---|---|
| Setting Method | Potentiometer |
| Housing Material | Plastic |
| Degree of Protection | IP67 |
| Connection | M12 × 1; 4-pin |
| Weight | 70 g |
Safety-relevant Data |
|
|---|---|
| MTTFd (EN ISO 13849-1) | 1,930.46 a |
Output |
|
|---|---|
| Contamination Output | yes |
| PNP NO | yeS |
