flare 24DC-2W-250V6A-F
Compact coupling relay
24 V DC
80.010.4103.0

Compact coupling relay

Input voltage range 19,2 … 30 V DC

2 changeover contacts

Mounting width 12,4 mm

lare 24DC-2W-250V6A-F Order no. 80.010.4103.0
Coil circuit
Operating voltage 24 V DC
Minimum input voltage 19,2 V DC
Maximum input voltage 30 V DC
Nominal input current 18 mA
Nominal input capacity 0,45 W
Status display LED green
Switching characteristics
Contacts 2 changeover contacts
Contact material AgSnO2
Maximum switching voltage 250 V AC/DC
Maximum continuous current 6 A (see Fig. 1 Load limiting curves)
Maximum starting current 10 A
Maximum switching current
DC1 30 / 110 / 220 V DC 6 A (see Fig. 1 Load limiting curves)
Maximum switching capacity AC 15 1500 V A / 120 W
Minimum selectable voltage 12 V
Minimum selectable current 5 mA
Mechanical life 20 x 106
Electrical life 80 x 103
(230 V AC); 60 x 104
(24 V DC)
