Sensor / Photocell Barrier;
With Polarized Filter;
Operating range: 0 … 150mm
Operating range, white 90%: 25 … 100mm
Operating range, gray 18%: 25 … 130mm
Operating range, black 6%: 25 … 100mm
Adjustment: 25 … 150mm
Sensitivity adjustment by 270° Potentiometer;
Light spot diameter: < 1mm adjustable via collimator
Light Type: Visible laser 760nm
​Sampling Frequency: up to 5000Hz;
Response time: 0.1 ms
Output > 1x PNP transistor
Switching principle: Light-Dark switching
Power supply: 10 to 30 V, DC, including residual ripple
Load current: 0 … 200 mA
Connection type: 2000mm 4×0.14mm2 cable output
Housing material: Metal – Injected aluminum;
WxHxD dimensions: 15 mm x 34 mm x 30 mm
Net weight: 100 g
Degree of protection: IP67;
Valid set of standards: IEC 60947-5-2
Tax classification: 85.36.50.19

LEUZE ELECTORONIC LS 7824 RE
