Features
Functional principle Photoelectric proximity sensor
Functional principle detail Background suppression
Sensing range max. 4 mm … 150 mm 1)
Sensing range 15 mm … 150 mm 1)
Emitted beam
Light source PinPoint LED 2)
Type of light Visible red light
Light spot size (distance) Ø 7 mm (50 mm)
Key LED figures
Wave length 650 nm
Adjustment Potentiometer, 5 turns
Special applications Detecting small objects
1) Object with 90% remission (based on standard white, DIN 5033).
2) Average service life: 100,000 h at TU = +25 °C.
Safety-related parameters
MTTFD 1,187 years
DCavg 0 %Electrical data
Supply voltage UB 10 V DC … 30 V DC 1)
Ripple < 5 Vpp
2)
Current consumption 20 mA 3)
Protection class III
Digital output
Type PNP
Switching mode Light switching
Output current Imax. ≤ 100 mA
Response time < 0.5 ms 4)
Switching frequency 1,000 Hz 5)
Circuit protection A 6)
