Enclosure

thermoplastic, glass-fibre reinforced, shockproof, self-extinguishing UL 94 V-0

Sensor type

type 4 interlocking device

Coding level

low coding

Degree of protection

IP67 (IEC/EN 60529)

Switching system

reed contacts

Switching elements

2 NC contacts

Connection

Pre-wired cable 4 x AWG 24 UL

Cable cross-section

4 x 0.22 mm²

Cable length

2 m

Switching voltage

max. 30 VDC

Rated operating current/voltage Ie/Ue

max. 125 mA / 24 VDC

Voltage drop at Ie

max. 2.5 V

Assured switching distance »OFF« sar

> 23 mm

Repeatability

< 0.5 mm

Hysteresis

min. 23 mm

Degree of pollution

3

Safety class

II

Ambient temperature

T6: –20 °C … +70 °C,
T5: –20 °C … +85 °C

Mechanical life

> 1 million operations

Impact energy

max. 7 J
