Specifications
SENSING RANGE
SENSITIVITY ADJUSTMENT
BACKGROUND SUPPRESSION
MODEL NUMBER(S)
/47
/48
/49
SUPPLY VOLTAGE
LED(s)
CURRENT CONSUMPTION
OPERATING MODE
RESPONSE TIME
SWITCHING FREQUENCY
LIGHT SPOT DIAMETER
LIGHT BEAM ANGLE
LIGHT SOURCE
AMBIENT LIGHT RESISTANCE
ELECTRICAL CONNECTION
ADDITIONAL DATA
10-80mm
No
From 90mm
MLV40-8-H-80/47/115
MLV40-8-H-80/48/115
MLV40-8-H-80/49/115
2 PNP
2 NPN
1 NPN and 1 PNP
10-30VDC
Yes (1)
≤40mA
Light on/dark on (D.O. for /49)
≤5.0ms
70Hz
≈10mm at a range of 80mm
≈7º
Infrared LED
≤100,000 lux
2-meter cable,
PVC covered
4-conductor
OUTPUT: Transistor
10-150mm
Yes
Adjustable
—
—
MLV40-8-H-150-65/40a/49/92
—
—
1 NPN and 1 PNP
10-30VDC
Yes (1)
≤40mA
Light on/dark on
≤5.0ms
70Hz
≈10mm at a range of 80mm
≈7º
Infrared LED
≤100,000 lux
Quick
disconnect
type V1

VISOLUX RLK 8-2000
